Silcon® Medical – Medical Grade Silicone Tubing
Silcon Medical tubing meets USP Class VI requirements. Its low surface energy helps to resist adhesion and does not support bacteria growth. The tubing is highly elastic without the need for plasticizers, making it a preferred option for life science use. Care is recommended in the selection and application of fittings and clamps as sharp barbed fittings or unlined metal clamps could tear into the tubing wall. Peroxide-cured Silcon Medical tubing is supplied in individual, non-sterile, heat-sealed polybags. Silcon Medical should not be used in continuous steam applications.
- Peroxide-cured
- Finished product meets USP Class VI requirements
- Raw materials meets FDA 21 CFR 177.2600 requirements for use with food contact surfaces
- Listed with NSF-51 for food and beverage equipment materials
- Able to resist extreme temperatures
- Free of BPA, latex and phthalates
- Naturally translucent so fluid flow is visible
- May be used for peristaltic pumping
- REACH and RoHS compliant
- Laboratory Uses
- Peristaltic Pumps
- Pharmaceutical Processing
| Value | |
|---|---|
| Hardness, Shore A ±5 | 60 |
| Tensile Strength, psi | 1305 |
| Elongation at Break, % | 429 |
| Tear Resistance, Die B, ppi | 177 |
| Modulus at 100%, psi | 230 |
NOTE: Values listed are typical for the material used in manufacture, except where noted, and are meant only as a guide to aid in design. Field testing should be performed to find the actual values for your application.
Cut Pieces – When tubing comes in, for example, 100 foot coils, and you need it in 10’ sections, tubing can be cut. Request a quote.
Size – Tubing is stocked in common I.D. and O.D. sizes, but this product can be custom extruded in other sizes. Let’s talk about what you need. Minimum quantities apply.
Color – Have your tubing colored to match equipment, company colors, or identify line (hot or cold, indoor or outdoor, chemicals, etc..).
All custom products are subject to minimum order quantities and lead times. For other custom options, please contact us.
Options & Sizes
|
Part Number
|
Suggested Sizes For
Pumps†† |
ID
(in) |
OD
(in) |
Wall
(in) |
Standard
Length (ft) |
|---|---|---|---|---|---|
| 2810304 | No | .030 | .065 | .018 | 50 |
| 2810381 | No | .031 (1/32) | .156 (5/32) | .063 (1/16) | 50 |
| 2810458 | Yes | .040 | .085 | .023 | 50 |
| 2810689 | No | .063 (1/16) | .125 (1/8) | .031 (1/32) | 50 |
| 2810766 | No | .063 (1/16) | .188 (3/16) | .063 (1/16) | 50 |
| 2810843 | Yes | .078 (5/64) | .125 (1/8) | .024 | 50 |
| 2810920 | No | .104 | .192 | .044 | 50 |
| 2810997 | No | .125 (1/8) | .250 (1/4) | .063 (1/16) | 50 |
| 2811151 | No | .188 (3/16) | .313 (5/16) | .063 (1/16) | 50 |
| 2811228 | Yes | .188 (3/16) | .375 (3/8) | .094 (3/32) | 50 |
| 2811305 | Yes | .250 (1/4) | .375 (3/8) | .063 (1/16) | 50 |
| 2811382 | Yes | .250 (1/4) | .438 (7/16) | .094 (3/32) | 25 |
| 2811459 | Yes | .250 (1/4) | .500 (1/2) | .125 (1/8) | 25 |
| 2811536 | No | .313 (5/16) | .438 (7/16) | .063 (1/16) | 25 |
| 2811613 | Yes | .313 (5/16) | .500 (1/2) | .094 (3/32) | 25 |
| 2811844 | Yes | .375 (3/8) | .625 (5/8) | .125 (1/8) | 25 |
| 2811921* | No | .500 (1/2) | .625 (5/8) | .063 (1/16) | 25 |
*Limited stock availability; lead times and minimums may apply — call for details.
Sold by standard coil length only.
Add length suffix to part number when ordering. Example: 50 ft. of .030” I.D. x .065” O.D. tubing is part number 281 0304-50.
††Most common peristaltic pump sizes based on I.D. and wall
requirements.
BOLD indicates the critical dimension for fittings application.
